Product Details
■ RF range: 400MHz to 6000MHz
■ 21dB typical gain at 3600MHz
■ 0.6dB typical NF at 3600MHz
■ +32.2dBm typical OIP3 at 3600MHz
■ 20.1dBm typical OP1dB at 3600MHz
■ 50Ω Single-ended input/output impedances
■ +5V power supply
■ IDD = 70mA
■ Standby mode for power saving
■ 1.8V/3.3V logic standby control
■ Operating temperature (TEP) range: -40°C to
+115°C
■ 2 × 2 mm, 8-DFN package
F0180 is a high-performance low-noise amplifier designed to operate in the 0.4 - 6 GHz spectrum covering the coveted 5G NR bands like n77, n78, among many other bands in the frequency range. F0180 delivers best-in-class NF of 0.6dB at 3.6 GHz, while achieving 21dB gain and >32 dBm OIP3 with >20 dBm OP1. F0180 is a standalone solution for a wide operating spectrum, covering applications such as 4G LTE and 5G NR.
■ 5G wireless infrastructure
■ Repeaters/DAS
■ Public safety infrastructure
■ General-purpose RF
Part Number (7)
RTKA81F01800P500RU
RTKA81F01804P700RU
RTKA81F01803P600RU
RTKA81F01802P100RU
RTKA81F01800P700RU
RA81F0180STGNS#KB0
RA81F0180STGNS#BB0
