F0424

高-Gain Broadband RF Amplifier 600MHz to 5000MHz

数据表 联系销售人员

产品详情

0
0thubnail
  • RF 范围: 600MHz to 5000MHz
  • Noise figure = 2.3dB at 2600MHz
  • Gain = 17.3dB at 2600MHz
  • OIP3 = +40dBm at 2600MHz
  • Output P1dB = +21dBm at 2600MHz
  • Near-constant gain versus temperature
  • 3.3V or 5V power supply
  • ICC = 70mA
  • 2mA standby current
  • 350mW typical DC power at 5V supply
  • 50Ω input and output impedances
  • Operating temperature (TEP) 范围: -40 °C to +105 °C
  • 2mm × 2mm, 8-DFN package

The F0424 is a 600MHz to 5000MHz SiGe 高-gain broadband RF amplifier. The combination of low noise figure (NF) and 高 linearity performance allows the device to be used in both receiver and transmitter 应用s.

The F0424 is designed to operate with a single 5V or 3.3V power supply using a nominal 70mA of ICC. With a supply voltage of 5V, the F0424 provides 17.3dB gain with +40dBm OIP3 and 2.3dB noise figure at 2600MHz.

This device is packaged in a 2mm × 2mm, 8-DFN with 50Ω single-ended RF input and output impedances for ease of integration into the signal path.

  • 4G TDD and FDD Base Stations
  • 2G/3G Base Stations
  • Repeaters and DAS
  • Point-to-Point 基础设施
  • Public Safety 基础设施
  • Military Handhelds

产品文档

数据表

2025-08-04

F0424 数据表

pdf | 3.94 MB
帮助
Filters
to

部件号s (2)

F0424NTGK

查看 数据表
查看 Block Diagram
查看 细节

F0424NTGK8

查看 数据表
查看 Block Diagram
查看 细节
