产品详情
- Dual path for MIMO systems
- 9.0 dB Gain; ultra linear
- +39 dBm IP3O
- Low NF ~ 9 dB
- Extended LO level 范围 for MIMO (-6 dBm)
- 200 ohm output impedance
- Very 高 +11 dBm P1dBI
- Pin compatible with IDT's Zero-Distortion family
- 6x6 mm 36-pin package
- Individual path power down mode
- < 200 nsec settling from power down
- Minimizes synthesizer pulling in standby mode
The IDT F1178 dual channel device operates with a single 5 V supply. It is optimized for operation in a Multicarrier BaseStation Receiver for RF bands from 3300 to 3800 MHz with 高 or Low Side Injection. IF frequencies from 20 to 550 MHz are 支持ed. matching modifications. Nominally, the device offers +39 dBm Output IP3 with 290 mA of ICC.
A member of IDT’s Zero-Distortion™ family, this RF to IF mixer reduces distortion for improved SNR while simultaneously reducing power consumption.
