产品详情
- RF 范围: 400MHz to 3800MHz
- LO 范围: 400MHz to 3600MHz
- IF 范围: 50MHz to 600MHz
- Dual path for MIMO
- 4 gain settings: 11dB, 8dB, 5dB, 2dB
- 2-bit gain 步 control
- Ideal for multi-carrier systems
- +35dBm OIP3
- Low noise figure at any gain setting via FlatNoise™ technology
- Z = 200Ω IF balanced, 50Ω RF, 50Ω LO single-ended
- All internally matched. Single BOM for all RF, LO, and IF frequencies
- 4mm x 4mm, 24-TQFN package
- Independent Path Standby mode
- 75nsec settling for gain adjustment
- VCC = 3.3V, 835mW
The F1192B dual-channel RF mixer offers maximum performance and flexibility at minimum power consumption. The unique and patented settable-gain feature allows it to be used in a very wide variety of radio card 应用s, even allowing for dynamic adjustment of gain to maximize performance on the fly. The extremely wide RF and IF bandwidths are achieved with a fixed BOM with all internal matching. The device can function with as little as -6dBm LO power and with independent channel shutdown modes for ease of integration into 高-订单 TDD MIMO systems. The F1192B has also been optimized for use in both GSM and LTE systems.
产品文档
类型
姓名
日期
动作
2025-07-13
PCN# : TB1912-02 Convert 船运 Media from Tube or Tray to Cut Reel
2025-07-13
PCN# : TB1912-02(R1) Convert 船运 Media from Tube or Tray to Cut Reel
