产品详情
- Broadband 450MHz to 1100MHz
- 32dB max gain
- 3.6dB NF at max gain (900MHz)
- 29.5dB total gain control 范围, 0.5dB 步
- < 2dB overshoot between major gain transitions
- +41dBm OIP3
- Maintains +23dBm output P1dB over 13dB gain adjustment 范围
- SPI interface for DSA control
- Single 5V supply voltage
- ICC = 185mA
- Up to +105°C TCASE operating temperature
- 50Ω input and output impedance
- Standby for power savings
- Pin compatible 1400–2300 MHz and 2100–2950 MHz versions
- 6 × 6 mm, 28-QFN package
The F1451 is a 高-Gain/高-Linearity 450MHz to 1100MHz TX Variable Gain Amplifier used in transmitter 应用s. The F1451 TX VGA provides 32dB maximum gain with +41dBm OIP3 and 3.6dB noise figure. Up to 29.5dB gain control is achieved using the combination of a digital 步 attenuator (DSA) plus KLIN™ RF variable gain amplifier gain adjustment. This device uses a single 5V supply and 185mA of ICC. This device is packaged in a 6 × 6 mm, 28-QFN with 50Ω single-ended RF input and RF output impedances for ease of integration into the signal path.
