F1420

RF Amplifier 700MHz to 1.1GHz

数据表 联系销售人员

产品详情

0
0thubnail
  • Broadband 700MHz to 1.1GHz
  • 17.4dB typical gain at 960MHz
  • 4.5dB noise figure at 960MHz
  • +42dBm OIP3 at 960MHz
  • +23.2dBm output P1dB at 960MHz
  • Single 5V supply voltage
  • ICC = 105mA
  • -40 °C to +105 °C operating temperature
  • 50Ω single-ended input/output impedances
  • Standby mode for power savings
  • 4mm x 4mm 24-QFN package

The F1420 is a 高-gain/高-linearity RF amplifier used in 高-performance RF 应用s. The F1420 provides 17.4dB gain with +42dBm OIP3 and a 4.5dB noise figure at 960MHz, and uses a single 5V supply and 105mA of ICC. The F1420 is packaged in a 4mm x 4mm 24-QFN with 50Ω RF input and RF output impedances for ease of integration into the signal path.

产品文档

数据表

2025-07-10

F1420 数据表 - RevO

pdf | 2.11 MB
Product Change Notice

2025-07-10

PCN#: TB1901-01 Add Alternate Test Location on 选择 Devices

pdf | 24.55 KB
帮助
Filters
to

部件号s (2)

F1420NLGK

查看 数据表
查看 Block Diagram
查看 细节

F1420NLGK8

查看 数据表
查看 Block Diagram
查看 细节
