产品详情
- Frequency: 17.7GHz – 21.2GHz
- Gain: 22dB
- Noise Figure: 1.2dB
- Output P1dB: -2dBm
- Power consumption: 15mW/ch
- Supply voltage: 1.2V nominal
- Compact size for planar integration on λ/2 grid
- 2.7 × 2.7 × 0.9 mm, 23-pin BGA
- -40°C to +85°C ambient operating temperature 范围
The F6932 is an ultra-low power consumption, dual-channel, silicon on insulator (SOI) low noise amplifier (LNA) RFIC designed for 应用 in Ka‑Band SATCOM planar phased array antennas. The exceptional combination of low power consumption, low noise, 高 gain, and compact size, maximizes the antenna array G/T while minimizing overall system power dissipation.
The F6932 includes two LNA channels in a compact 23-pin, 0.5mm pitch BGA package. All inputs and outputs are single-ended and 50Ω matched for ease of integration onto phased array antenna panels.
