产品详情
- RF 范围: 400 MHz to 3800 MHz
- LO 范围: 400 MHz to 3600 MHz
- IF 范围: 50 MHz to 600 MHz
- 4 gain settings; 11 dB, 8 dB, 5 dB, 2 dB
- 2-bit gain 步 control
- Ideal for Multi-Carrier systems
- +35 dBm OIP3
- Low noise figure at any gain setting via IDT’s FlatNoise™ technology
- Z = 200 Ω IF balanced, 50 Ω RF, 50 Ω LO single ended
- All internally matched. Single BOM for all RF, LO and IF frequencies
- 4 mm x 4 mm, 24-pin TQFN package
- Independent Path Standby mode
- 75 nsec settling for gain adjustment
- VCC = 3.3 V, 462 mW
The F1792 offers maximum performance and flexibility at minimum power consumption. The unique and patented settable-gain feature allows it to be used in a very wide variety of radiocard 应用s, even allowing for dynamic adjustment of gain to maximize performance on the fly. The extremely wide RF and IF bandwidths are achieved with a fixed BOM with all internal matching. The device can function with as little as -6 dBm LO power and with independent channel shutdown modes for ease of integration into 高 订单 TDD MIMO systems.
