F2977

高 Linearity Broadband SP2T 30MHz to 6GHz RF Switch

数据表 联系销售人员

产品详情

0
0thubnail
  • Low insertion loss
    • 0.38dB at 2.4GHz
    • 0.45dB at 6GHz
  • 高 Isolation:
    • 34dB at 2.4GHz
    • 26dB at 6GHz
  • 高 Linearity:
    • IIP2 +120dBm at 2.4GHz
    • IIP3 +77dBm at 2.4GHz
  • P0.1dB compression of +40dBm
  • Second Harmonic: -86dBc at Fin = 1.8GHz, Pin = 33dBm
  • Third Harmonic: -89dBc Fin = 1.8GHz, Pin = 33dBm

The F2977 is a 50Ω single-pole double-throw (SP2T) reflective RF switch featuring 高 linearity and wide bandwidth. This device is optimized from 30MHz to 6GHz to 支持 a multitude of wireless RF 应用s. The F2977 uses a single positive supply voltage of either +3.3V or +5.0V and is compatible with either 1.8V or 3.3V control logic.

产品文档

数据表

2025-07-10

F2977 数据表 Rev O

pdf | 3.19 MB
Model - S-parameter

2025-07-10

F2977 S-Parameters

zip | 716.17 KB
帮助
Filters
to

部件号s (2)

F2977NEGK

查看 数据表
查看 Block Diagram
查看 细节

F2977NEGK8

查看 数据表
查看 Block Diagram
查看 细节
