产品详情
- 400MHz to 2700MHz; < 1dB overshoot between gain transitions
- 13dB typical max gain
- 23dB gain 范围, 1dB gain 步 resolution
- Excellent linearity +41dBm OIP3
- Noise figure 4dB
- ICC = 100mA
- 1.3mA standby current
- SPI interface
- Broadband, Internally Matched
The F0480 RF Variable Gain Amplifiers (VGA) featuring Glitch-Free™ and Zero-Distortion™ technologies greatly reduces attenuation overshoot during attenuation 状态 changes and provides +41dBm OIP3 performance across a very wide bandwidth of 400MHz to 2700MHz at a typical current drain of 100mA. Furthermore, the device is internally matched so there is no need to optimize external matching elements.
- Multi-mode, Multi-carrier Receivers
- PCS1900 Base Stations
- DCS1800 Base Stations
- WiMAX and LTE Base Stations
- UMTS/WCDMA 3G Base Stations
- PHS/PAS Base Stations
- Point-to-Point 基础设施
- Public Safety 基础设施
- Broadband Repeaters
- GPS Receivers
- Distributed Antenna Systems
- Cable 基础设施
- Digital Radio
